Description

Features

  • MX3 is a Mesh Wi-Fi system designed to provide whole-home Wi-Fi 6 for medium to large houses. Supporting Easymesh technology, the MX3 is equipped with high-performance enhancement modules for powerful penetration and broader coverage.
  • With mesh technology, MX3 creates a distributed WiFi network that covers up to 200㎡, eliminating WiFi dead zones at your home
  • MU-MIMO technology, MX3 supports more WiFi-enabled devices. And the smart QoS intelligently allocates bandwidth to ensure smooth streaming, gaming, downloading and uninterrupted video chat at the same time
  • With one single SSID and password, MX3 automatically performs handover without interrupting services to ensure that the devices are always connected to the WiFi network with stronger signals
  • Pre-paired from factory settings makes setup of MX3 a breeze, letting you go from burden of cabling connections
  • Easily manage your Tenda ecosystem through the Tenda app

Specifications

Hardware Features

Standard and Protocol IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Ethernet Interface 10/100/1000Mbps WAN port*1
10/100/1000Mbps LAN port*1
Antenna 2 x 3dBi Internal antenna
Button 1 x Reset Button
1 x MESH Button
Power Input: AC 100-240V~50/60Hz
Output:DC 12V⎓1A
Dimension 90*90*93 mm (3.54*3.54*3.65 in.)
LED Indicator 1 x Tri-color LED
Indicator(Green,Yellow,Red)


Wireless Features

Wireless Standard
2.4GHz:IEEE 802.11n/b/g
5GHz:IEEE 802.11ax/ac/n/a
Wireless Roaming Comply with IEEE802.11k/v
Mesh Network  Tenda EasyMesh
Rate 5GHz:1201Mbps
2.4GHz:300Mbps
Frequency  2.4GHz & 5GHz
Transmission Power CE:
<20dBm(2.4GHz)
<23dBm(5GHz)
FCC:
<30dBm(2.4GHz)
<30dBm(5GHz)
Basic Features OFDMA
MU-MIMO
Beamforming
Wireless Security WPA2-PSK
WPA3-SAE/WPA2-PSK
Wireless Encryption Disable and Enable
WPS Fast Connection


Software Features

Operating Mode
Router Mode,AP Mode
Internet Connection Type
PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)
DHCP Server
DHCP Server, DHCP Client List
Virtual Server
Port Forwarding, UPnP
Parental Control
Client Filter
Firewall
Forbid TCP/UDP flood attack
VPN
PPTP/L2TP/IPsec pass through
DNS
Support manually setting DNS server
Special Features WPA3
TR069
Tenda EasyMesh
Unify 2.4 GHz & 5 GHz
Smart LED on/off
Amazon Alexa
One-button Fault Diagnosis
Broadband Account Migration
Tenda App: Local and Remote ManagementSpeed Test
Monthly Report
Others IPTV
IPv6
Guest Network
System Log
Remote Web Management
MAC Clone
Backup & Restore configurations
Support automatic access detection
Firmware upgrade online


Others

Operating Temperature
0 ~ 40 ℃
Storage Temperature
-40 ~ 70 ℃
Operating Humidity
10%~90% RH non-condensing
Storage Humidity
5%~90% RH non-condensing
APP Installation
Available in iOS 8.0 or later, Android 4.0 or later
Certification
CE, FCC, RoHS,EAC,IC
Package Contents

Mesh,

QIG x 1,

RJ45 Gigabit Ethernet cable x 1
