Description
- Wireless Speed: 11AC wireless technology with speeds up to 867Mbps.
- Antenna: 12dBi dual polarization directional antenna for stable long-range connections.
- Ports: Four fast Ethernet ports for wired connections.
- Weather-Resistant: IP65 waterproof enclosure for outdoor durability.
- Lightning Protection: 6000V lightning protection for enhanced safety.
- Power Options: Supports 12V 1A Passive PoE and 12V 1A DC for flexible deployment.
Performance:
- Range: Up to 5+km with stable long-distance wireless connectivity.
- TD-MAX Protocol: Tenda's proprietary TDMA (Time Division Multiple Access) protocol improves performance by coordinating data transmission and reducing latency.
- Auto-Bridge Technology: Automatically connects CPEs or base stations upon power-up, simplifying setup for non-experts (ideal for CCTV surveillance).
Management:
- Centralized Management: CPE Assistant software for managing all devices in the network from a single PC.
Design:
- Weather Protection: IP65 rating ensures performance in rain, sun, and extreme temperatures.
- Flexible Setup: Supports both wireless and wired setups for easy internet access.
Hardware
| Model | OS3 |
| Dimension | 193*109*61mm |
| Deployment | Pole Mount/Wall Mount |
| Application Scenarios | PtP and PtMP wireless connection for Privated ISP access or CCTV Surveillance |
Hardware
| Frequency Range | 5GHz |
| Compliant Standards | IEEE 802.11a/n/ac |
| Maximum Wireless Rate | 867Mbps |
| Interfaces | 4*10/100 LAN Port |
| Antenna | - |
| Antenna Gain |
12dbi |
| Antenna Beamwidth | Horizontal: 30° Vertical: 30° Elevation: 30° |
| GND | \ |
| Reset Button | 1*Reset Button |
| Power Consumption | 4.7W |
| Waterproof Level | IP65 |
| LED Indicator | Power,PoE/LAN1,LAN2,LAN3,LAN4LED1,LED2,LED3 |
| Power Method |
12V 1A Passive PoE 12V 1A DC |
| Lightning Protection | 6000V |
| Passive PoE |
Passive power over ethenet via PoE/LAN (+4,5pins -7,8pins) Voltage range: 9-13.8V DC |
| Reception Sensitivity |
11b 1Mbps -92dBm±1.5dBm 11n MCS0: -92±1.5dBm 11n MCS7: -72±1.5dBm |
Software
| TDMA | \ |
| Operating Mode | AP/Station/WISP/P2MP/WDS Repeater/Router |
| Enable/Disable Wireless Radio | Support |
| SSID Hidden | Support |
| Wireless Client isolation | Support |
| SSID Isolation | Support |
| Channel Bandwidth |
20/40/80MHz |
| Channel Shift | \ |
| Wireless Access Control | Support |
| Weak Signal Client Limitation | Support |
| Transmission Power | Adjustable power by 1dBm |
| WMM Capable | Support |
| APSD Capable | Support |
| Wireless Security |
64/128 WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2 |
| Transparent Bridge | Support |
| VLAN Tagging for SSID | Support |
| DHCP Server |
Support |
| VPN Pass-Through | PPTP,L2TP |
| Remote Web access | Support |
| Schedule Reboot | Support |
| Page Timeout | Support |
| Ping Watchdog | Support |
| Dyndns | noip, dyndns.org |
| Network Diagnoses | Ping, Traceroute, Signal Scan |
| Time and Date Setting | Support |
| Firmware upgrade | Support |
| Backup/Restore Configuration | Support |
| Username Managerment | Support |
| System Logs | Support |
| Managed By Controller | PC Software CPE Assistant |
Others
| Package Contents |
1*5GHz 12dBi 11AC 867Mbps Outdoor CPE 1*Power Adapter 1*PoE Injector 1*Quick Installation Guide |
| Operation Temperature | -30℃ ~55 ℃ |
| Storage Temperature | -40℃ ~ 70℃ |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 10%~90% non-condensing |
| Default login IP | 192.168.2.1 |
| Default Login Username | admin |
| Default Login Password | admin |
| Certification | FCC/CE/RoHS |
Description
- Wireless Speed: 11AC wireless technology with speeds up to 867Mbps.
- Antenna: 12dBi dual polarization directional antenna for stable long-range connections.
- Ports: Four fast Ethernet ports for wired connections.
- Weather-Resistant: IP65 waterproof enclosure for outdoor durability.
- Lightning Protection: 6000V lightning protection for enhanced safety.
- Power Options: Supports 12V 1A Passive PoE and 12V 1A DC for flexible deployment.
Performance:
- Range: Up to 5+km with stable long-distance wireless connectivity.
- TD-MAX Protocol: Tenda's proprietary TDMA (Time Division Multiple Access) protocol improves performance by coordinating data transmission and reducing latency.
- Auto-Bridge Technology: Automatically connects CPEs or base stations upon power-up, simplifying setup for non-experts (ideal for CCTV surveillance).
Management:
- Centralized Management: CPE Assistant software for managing all devices in the network from a single PC.
Design:
- Weather Protection: IP65 rating ensures performance in rain, sun, and extreme temperatures.
- Flexible Setup: Supports both wireless and wired setups for easy internet access.
Hardware
| Model | OS3 |
| Dimension | 193*109*61mm |
| Deployment | Pole Mount/Wall Mount |
| Application Scenarios | PtP and PtMP wireless connection for Privated ISP access or CCTV Surveillance |
Hardware
| Frequency Range | 5GHz |
| Compliant Standards | IEEE 802.11a/n/ac |
| Maximum Wireless Rate | 867Mbps |
| Interfaces | 4*10/100 LAN Port |
| Antenna | - |
| Antenna Gain |
12dbi |
| Antenna Beamwidth | Horizontal: 30° Vertical: 30° Elevation: 30° |
| GND | \ |
| Reset Button | 1*Reset Button |
| Power Consumption | 4.7W |
| Waterproof Level | IP65 |
| LED Indicator | Power,PoE/LAN1,LAN2,LAN3,LAN4LED1,LED2,LED3 |
| Power Method |
12V 1A Passive PoE 12V 1A DC |
| Lightning Protection | 6000V |
| Passive PoE |
Passive power over ethenet via PoE/LAN (+4,5pins -7,8pins) Voltage range: 9-13.8V DC |
| Reception Sensitivity |
11b 1Mbps -92dBm±1.5dBm 11n MCS0: -92±1.5dBm 11n MCS7: -72±1.5dBm |
Software
| TDMA | \ |
| Operating Mode | AP/Station/WISP/P2MP/WDS Repeater/Router |
| Enable/Disable Wireless Radio | Support |
| SSID Hidden | Support |
| Wireless Client isolation | Support |
| SSID Isolation | Support |
| Channel Bandwidth |
20/40/80MHz |
| Channel Shift | \ |
| Wireless Access Control | Support |
| Weak Signal Client Limitation | Support |
| Transmission Power | Adjustable power by 1dBm |
| WMM Capable | Support |
| APSD Capable | Support |
| Wireless Security |
64/128 WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2 |
| Transparent Bridge | Support |
| VLAN Tagging for SSID | Support |
| DHCP Server |
Support |
| VPN Pass-Through | PPTP,L2TP |
| Remote Web access | Support |
| Schedule Reboot | Support |
| Page Timeout | Support |
| Ping Watchdog | Support |
| Dyndns | noip, dyndns.org |
| Network Diagnoses | Ping, Traceroute, Signal Scan |
| Time and Date Setting | Support |
| Firmware upgrade | Support |
| Backup/Restore Configuration | Support |
| Username Managerment | Support |
| System Logs | Support |
| Managed By Controller | PC Software CPE Assistant |
Others
| Package Contents |
1*5GHz 12dBi 11AC 867Mbps Outdoor CPE 1*Power Adapter 1*PoE Injector 1*Quick Installation Guide |
| Operation Temperature | -30℃ ~55 ℃ |
| Storage Temperature | -40℃ ~ 70℃ |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 10%~90% non-condensing |
| Default login IP | 192.168.2.1 |
| Default Login Username | admin |
| Default Login Password | admin |
| Certification | FCC/CE/RoHS |
