Description

Features

  • High-speed with VDSL Standards: Support VDSL2 Profile 35b,and also Compatible with VDSL,ADSL2+,ADSL2 and ADSL; AC1200 Dualband Wi-Fi:
  • Delivering both 867Mbps at 5GHz and 300Mbps at 2.4 GHz concurrently; Superior Wi-Fi
  • Coverage : 4*5dBi Antenna ,beamforming technology and MU-MIMO Technology;
  • Varies Backup Connectivity: Provide VDSL/ADSL and Ethernet WAN connection types by fiber or cable; 4*Full Gigabit Ethernet Ports: Gigabit wired speed for ultrafast data transfer
  • Super easy setup with the Tenda ecosystem

Specification

IEEE Standards IEEE802.11b/g/n,IEEE802.11ac, IEEE 802.3, 802.3u,IEEE 802.1Q
xDSL Standard&Protocol

ITU G.993.2, Up to 17a /30a/35b profile
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.INP)
Full-rate ANSI T1.413 Issue 2
ITU-T G.992.1(G.DMT)
ITU-T G.992.2(G.Lite)
ITU-T G.994.1 (G.hs)
ITU-T G.992.3 (G.DMT.bis)
ITU-T G.992.5

Interfaces
3 *10/100 RJ45 LAN Ports
1 *10/100 RJ45 LAN/WAN Port
1 *RJ11 Port
Dimension
220x141.6x59mm(W * D * H)
Button
WPS&Wi-Fi
RST
Power
External Power Supply
12V 1.5A
LED Indicator
Power
Internet
USB,LAN(1-4)
WPS
WLAN 2.4G
WLAN 5G
DSL
Certification
CE, RoHS
Protocols
Supports IPv4 and IPv6
ATM/PP Protocols
ATM Forum UNI3.1/4.0
PPP over ATM (RFC 2364)
PPP over Ethernet (RFC2516)
IPoA (RFC1577/2225)
MER\IPoE (RFC 1483 Routed)
Bridge (RFC1483 Bridge)
PVC – Up to 8 PVCs
WAN Connection
PPPoE
Dynamic IP
Static IP
Bridge
Business Type
TR069
Internet
IPTV
Services
DDNS
UPnP
Samba
FTP Server
Port Forwarding
DMZ
IPTV
DHCP Server
DHCP Server
Client List
Address Reservation
Quality of Service
QoS Settings
Management
Web Based Con guration(HTTP)
Remote management
command Line Interface
SSL for TR-069
SNMP v1/2c
Web Based Firmware Upgrade
Diagnostic Tools
Adv. Functions
Routing
Firewall
IP
Other Functions
VPN
ALG
Ping Diagnostics
System Log
DSL Statistics
Wireless Standard
IEEE 802.11a/n/ac 5GHz
IEEE 802.11b/g/n 2.4GHz
Bandwidth
20M/40M/80M
Channel Range
2.4G:Auto,CH1-CH13
5G: Auto,CH36-CH48
Antenna
4* 5 dBi Antenna
Wireless Speed
300Mbps at 2.4GHz
867Mbps at 5GHz
Transmission Power
2.4GHz <20dBm(EIRP)
5GHz <23dBm(EIRP)
Wireless Functions
Enable/Disable Wireless Radio
Wireless Repeating
Guest network
Access Control
WPS
Wireless Security
None, WPA,WPA2,WPA/WPA2
Storage Temperature -40°c ~ 70°c
Operation Temperature 0℃~40℃ (32℉ ~104℉)
Operating Humidity 10% ~ 90% (Non-condensing)
Storage Humidity 5% ~ 90% (Non-condensing)
Package Contents AC1200 Dualband Wi-Fi Gigabit VDSL Modem Router*1
External Splitter*1
Power Adapter*1
RJ11 DSL Cable*2
RJ45 Ethernet Cable*1
Quick Installation Guide*1
